ISO 分类 分组 代号 ISO Code |
牌号 Grade | 物理力学性能 Physical and Mechanical properties |
推荐用途 Applications recommended | ||
密度 Density G/cm | 硬度 Hardness HRA(HV) | 抗弯强度 TRS Mpa | |||
|
YG6X
|
14.9 |
92 |
1800 | 可用于应用不大的条件下,拉制直径0.6mm以下的钢丝,有色金属线材或棒材模。 It can used to make steel wire,non-ferrous metal wire or bar material with less than 6.0mm diameter |
YG6 |
YG6 |
14.9 |
90.5 |
2000 | 可用于较大应用条件下,拉制直径20mm以下的钢丝,有色金属及合金棒材,也可用于拉制直径10mm以下的管材。 It can be used for steel wire,non-ferrous metal and alloy bars under 20mm diameter,and can also be used for drawing pipes with diameter of less than 10mm. |
|
YG8 |
14.7 |
90 |
2200 | 可用于钢、有色金属及合金棒材和管材的拉丝,也可用于制造机械零件、工具及易损零件。 Can be used in steel,non-ferrous metal and alloy bars and pipes,also can be used in manufacturing machinery parts,tools and vulnerable parts. |
YG8.2 |
YG8.2 |
14.6 |
89 |
2000 | |
YG8L |
YG8L |
14.6 |
89 |
2000 | |
YG11 |
YG11 |
14.4 |
88.5 |
2300 | 可用于高压缩率钢棒和钢管拉伸,在较大应力下工作的顶锤、穿孔及冲压模具。 It can be used for high compression steel rod and steel pipe drawing,and the top hammer,perforation and stamping die of working under greater stress. |
YG15 |
YG15 |
14.0 |
87 |
2600 | |
YL50 |
YL50 |
14.4 |
87 |
2600 | |
YG20 |
YG20 |
13.6 |
85 |
2800 | 可用于制冲压模具、如冲压手表零件等,冲压电池壳,牙膏皮的模具,小尺寸的钢球、螺钉。螺帽等的冲压模具等。 It can be used for stamping die,such as punching watch parts,stamping battery shell,tooth paste mould,small size steel ball,screw,nut,etc. |
YG20C |
YG20C |
13.6 |
83.5 |
2800 |
可用于标准件,轴承,工具等行业用的冷锻,冷冲,冷压模具,弹头和弹壳的冲压模具。 It can be used in standard parts,bearings,tools and other industries for cold forging,cold pressing,clod pressing,cold pressing mould,warhead and shell stamping die. |
TL40.5 |
TL40.5 |
13.3 |
82 |
3000 |
